The dual ceramic ball bearing system provides optimal turbo response & better durability by reducing the shaft motion
13 Blade PTG-Aero billet compressor wheel 98mm inducer produces up to 2450 hp
9 Blade PTG-Aero Inconel 713c turbine wheel with more turbine flow
Fin cooled aluminum center housing, lighter weight
Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port
Installation Hardware: 4-inch flange kit for Comp. Outlet, 3.5-inch flange kit for Turb. Inlet, 5-inch flange kit for Turb. The outlet and oil Drain Fitting kits are included by default
Oil Feed Fitting(-4AN, 1.65mm (0.065-Inch) Orifice) included
Max Engine HP: 2450
Compressor Wheel: 98.4*133.5*142.4mm
Turbine Wheel: 112*106mm
Compressor Inlet: 6-Inch Hose
Compressor Outlet: 4-Inch V-Band
Housing Options:
Dual V band 1.09 A/R
Dual V band 1.24 A/R
Housing Style:
Standard Housing
Stainless Steel Wrapped Housing — available at additional cost
(Please allow 1-2 weeks for stainless steel wrapped housings if stock isn’t available.)
The Stainless Steel Wrapped Housing option adds an external stainless steel heat-retaining wrap around the turbine housing to help contain radiant heat around the turbine area.
Where listed, the turbocharger can also be selected without a turbine housing.
