BPP 1JZ / 2JZ Hall Sensor Kit

BPP 1JZ / 2JZ Hall Sensor Kit

Billet Performance Products 1JZ-GTE & 2JZ-GTE hall sensor kit replaces the original reluctor sensors with hall effect sensors, giving most aftermarket ECUs a cleaner signal.

BPP have found this leads to fewer trigger errors, better EMI resistance and easier starting on most ECUs.

Compatibility

Engine: Toyota 1JZ-GTE, 2JZ-GTE (non-VVTi & VVTi)
Vehicles: Toyota Supra JZA80, Aristo JZS161, Chaser / Cresta / Mark II JZX90 / JZX100, Soarer JZZ30

Wiring Pinout

Pin 1 - +Ve
Pin 2 - Signal
Pin 3 - Sensor Ground

ECU Setup

Trigger Edge - Falling
Pull up - Enabled

Why Choose BPP?

• Direct bolt-on.
• Deutsch DTM connectors (mating connectors supplied).
• Works with the stock 24 tooth and 36-2 (VVTi) trigger wheels.
• Tested to 10,000rpm.
• Available with or without a 2nd cam sensor block off.
